No.

Features

Description

1

Processor

8 - core high - performance ARM processor with a main frequency of 1.8GHz

2

Operating system

Android 13 operating system

3

Display screen

l   TFT LCD ：5.5 inch TFT HD 1080 x 1920 Pixels

l   Display Brightness：above 2000mcd；

l   Touch: Capacitive touch screen,supporting 10-point touch,with the surface layer made of tempered glass material.

4

Keyboard

l   Support virtual PIN input keyboard

5

Magnetic stripe
card reader

l   Supports triple - track magnetic stripe reading, two-way card swiping, and complies with ISO 7810/7811/7813 standards.

l   The card - swiping lifespan is greater than 400,000 times.

6

Smart card reader

l   Complies with EMV L1/L2, supports the ISO 7816 standard, and is capable of operating at voltages of 1.8V, 3V, and 5V. It supports both synchronous and asynchronous modes, as well as T=0 and T=1 protocols, with a lifespan of more than 300,000 times.

7

Contact less

card reader

l   Complies with the EMV Contact less L1 certification standard and supports the ISO 14443 A/B and ISO 15693 standards.

l   It is compatible with Mifare - series cards and Felica cards.

8

Front camera

l   Front - facing camera comes standard with 5MP and built - in fill light.

l   Optional installation of 3D structured light / binocular face recognition camera.

9

QR code scanning module

l   Supports 1D & 2D QR code scanning and mainstream code systems.

10

MIC

l   Capture audio data with a noise-canceling microphone.

11

Communication

methods

l   Supports LAN communication with 100M/1000M auto - adaptation.

l   Supports 4G/3G/2G communication.

l   Supports Wi-Fi (802.11 a/b/g/n/ac) 2.4GHz & 5GHz / Bluetooth 5.2.

12

GPS

l   Supports GPS/Galileo/BeiDou positioning.

13

External

interface

l   1 x 12V power adapter DC interface

l   10 x IO digital input - output interfaces, which can control IO.

l   1 x USB Type-A (Host) / 1 x USB Type-C (OTG)

l   2 x RS232 (RJ11 with power supply), 1 x LAN (RJ45).

l   1 x MDB-M interface, 1 x MDB-S interface.

l   1 x 3.5mm audio interface, 1 x HDMI interface

l   1 x SMA (4G) / 1 x SMA (WIFI) / 1 x SMA (GPS)

14

Card slot

interface

l   2 x SIM card slots, 2 x SAM card slots.

15

Security

Encryption

l   Hardware encryption, supporting multiple groups of master keys and working keys.

l   Supports algorithms such as DES/3DES, RSA, SM2, SM3, and SM4.

l   Self-destruct on unsealing; supports authorized relocation and setup

16

Audio

l   Built-in dual-channel speakers

17

Real-time

clock（RTC）

l   3V 550mAh battery, power-off retention for 5 years.

18

Power input

l   Wide voltage: DC 12V～48V

l   Current: 200mA during normal operation, maximum 500mA.

19

Overall Material

l   PC+ABS plastic/stainless steel material

20

Physical

Characteristics

l   Overall dimensions：180 (L) x 103.8(W) x54.5(D) mm

l   Installation dimensions：107 (L) x 80(W) x9.5(D) mm

l   Weight：550g

21

Environmental

Adaptability

l   Working temperature：-20℃～+70℃

l   Storage and transportation temperature: -30℃～+70℃

l   Relative humidity：  5%～95%

22

Protection level

l   IK protection level IK09

l   Waterproof rating IP65

l   ESD: Can withstand electrostatic attacks of ±8KV contact discharge and ±10KV air discharge.

l   EFT: Can pass the anti - interference test with a repetition frequency of 100 KHz and a voltage of 1000 V.

l   Surge: Can withstand the surge impact of ±1KV between lines and ±2KV between line and ground.

l   RE/RS：It is capable of meeting the requirements of Class B equipment standards in EN55032 and EN55035.

l   High - frequency noise: It is able to pass the high - frequency noise test of ±1 KV.

23

Product

Certification

l   PCI PTS 7.x / EMV L1 / EMV CL1 / EMV L2 / TQM

l   CE / FCC Certification

l   ATEX Certification / IP65 / IK09
